A1C
Equipped with drive wheels in aluminum alloy with horizontal motor suitable for limited static loads
application
Sweeping motorcycles and light floor cleaners or forklifts with a floating motor wheel loaded by a central spring for adhesion
description
The latest models of the A1C series use a gasket system like the ‘G’ series models that allow you to work even in the presence of water without damaging the gearbox in the least
| Ratio |
1:20 - 1:34 |
| DC-AC Motor |
700 ÷ 1200 W |
| Voltage |
12 ÷ 48 V |
| Wheel |
ø=245/250
h=76/101 |
| Wheel Material |
Rubber
Polyurethane 60÷92 Sh
No Marking Rubber |
| Max Load |
360 ÷ 600 Kg |
| Brake |
4,5 ÷ 10 Nm |
| Encoder |
32/64 Pulse |
| Speed Max |
5 ÷ 8 Km/h |
| Handling Equipment Up |
2500 Kg |
| Cleaning Equipment Up |
650 Kg |
| Max Torque |
364 Nm |
| 2000 h Torque |
159 ÷ 181 Nm |
